Lost Wax Casting Stainless Steel Parts

Lost Wax Casting Stainless Steel Parts

Lost Wax Casting Stainless Steel Parts

OEM Stainless Steel Disposer Part

Manufacturing: Investment Casting + CNC Machining

Weight: 3.00 kg

Surface Treatment: Oil

OEM & ODM Services

China Foundry

No Min Order

New products

OEM Universal Coupling Joint Part Manufacturer



The stainless steel universal coupling joint parts is designed to connect two shafts and provides a strong attachment mechanism.The ability of OEM universal coupling parts to joint dissimilar pipe materials is a bonus feature in both repair or permanent situation.

OEM & ODM Investment Casting Steel Parts for Foodservice Industry from Hengchang Foundry

The Custom Stainless Steel Parts are produced by investment casting, It is an industrial process based on lost-wax casting, one of the oldest known metal-forming techniques.The term "lost-wax casting" can also refer to modern investment casting processes.

Investment casting has been used in various forms for the last 5,000 years. In its earliest forms, beeswax was used to form patterns necessary for the casting process. Today, more advanced waxes, refractory materials and specialist alloys are typically used for making patterns. Investment casting is valued for its ability to produce components with accuracy, repeatability, versatility and integrity in a variety of metals and high-performance alloys.

The fragile wax patterns must withstand forces encountered during the mould making. Much of the wax used in investment casting can be reclaimed and reused. Lost-foam casting is a modern form of investment casting that eliminates certain steps in the process.

Investment casting is so named because the process invest (surrounds) the pattern with refractory material to make a mould, and a molten substance is cast into the mold. Materials that can be cast include stainless steel alloys, brass, aluminium, carbon steel and glass. The cavity inside the refractory mould is an exact duplicate of the desired part. Due to the hardness of refractory materials used, investment casting can produce products with exceptional surface qualities, which can reduce the need for secondary machine processes.

Water glass and silica sol  investment casting are the two primary investment casting methods nowadays. The main differences are the surface roughness and cost of casting. Water glass method dewaxes into the high-temperature water, and the ceramic mould is made of water glass quartz sand. Silica sol method dewaxes into the flash fire, and silica sol zircon sand makes the ceramic mould. Silica sol method costs more but has the better surface than the water glass method.

The process can be used for both small castings of a few ounces and large castings weighing several hundred pounds. It can be more expensive than die casting or sand casting, but per-unit costs decrease with large volumes. Investment casting can produce complicated shapes that would be difficult or impossible with other casting methods. It can also produce products with exceptional surface qualities and low tolerances with minimal surface finishing or machining required.



Product details

Material lead alloy, brass, carbon steel, copper, aluminum, alloy steel, etc
standard ASTM, ASME,DIN, EN, BS, JIS, ANSI, AS,GB etc.
process Investment casting, Green sand casting ,resin sand casting, shell molding casting,vacuum casting, continuous concast, machining
Weight range 0.5-2,000kg
Surface treatment painting, polishing, heat treatment, annealing or galvanization etc.
Size and design As per the customer's drawings, samples and requirements
Machining complete machining such as CN machining,CNC lathe,CNC milling,drilling etc.
Packing As per customers' requirements
Inspection in-house or the third Party

Advantages of Investment casting

  • Excellent surface finish
  • High dimensional accuracy
  • Extremely intricate parts are castable
  • Almost any metal can be cast
  • No flash or parting lines
  • Effective utilization of metal
  • Fewer environmental hazards from the foundry process

Zhangzhou Hengchang Machinery Manufacturing Co.,Ltd production process.
